Specifications
Engine
Cummins 4BT3.9-G4 turbocharged 4 cylinder diesel standard. Meets EPA Mobile Off Highway, California CARB requirements.
Frequency Control
Woodward digital electronic controller with integrated actuator. No exteral linkage to maintain. Crystal accuracy for HMI lighting.
Controller
Engine control, AC monitoring, fault and pre-fault systems are provided by a microprocessor-based system. All readouts are digital and are listed below. Weather-proof glass cover.
Monitoring | Faults & Pre-Faults |
AC Voltage - All Legs | Oil Pressure Fault/Pre-Fault |
Amperage - All Legs | Water Temp Fault/Pre-Fault |
Frequency - All Legs | Over Crank Fault |
Oil Pressure | Over Speed Fault |
Water Temperature | Low Fuel Fault/Pre-Fault |
Battery Voltage | Low Battery Pre-Fault |
Fuel Level | Defective Oil Sending Unit Pre-Fault |
Time to Next Service | Defective Water Sending Unit Pre-Fault |
Generator
Lima/Marathon MagnaPLUS 94KW with Single Phase/Three Phase Switch. Provides full 500A @120V output in Single Phase and in Three Phase. Marine rated rectifier with surge suppression. CSA listed.
Voltage Regulator
Lima/Marathon SE 350 with remote voltage adjustment. UL and CSA listed.
Circuit Breaker
250 amp breaker protects equipment in either single or three phase. Weather-proof glass cover. UL and CSA listed.
Electrical Connection
2 rows of UL listed Cam-Lok type connectors with male and female grounds. 2 Edison 20A outlets with separate breakers provided for convenience outlets. Engine block heater connection. NEC approved panel.
Size/Weight
With Trailer: Length: 154″, Width: 86″, Height: 72
Weight: Trailer, generator, and fuel: 3500Ibs. (1590 kg)
Noise Level
Less than 50 db(A) @ 50 feet.
Fuel Tank
60 gallons on board.
Load | Hours Running Time |
500A | 14:45 |
375A | 18:45 |
250A | 25:20 |
125A | 42:00 |
